CG-1964 CG-1965 10L JACKETED

10L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR

Pilot Plant Reactors 10L-100L

Complete glass reactor system on our NEW open air, auto-center stand. PLEASE NOTE: REACTOR STAND OVERALL HEIGHT WITH MOTOR AND CLEARANCE BELOW VALVE, ARE CALCULATED FOR ALL CHEMGLASS STIRRER BEARINGS, INCLUDING THE CG-2077-M MECHANICAL SEAL STIR BEARING.

Features:

• New & Improved Open Frame Design Provides Excellent Accessibility
• Support Frame with Oversized Rugged S.S. Uprights and Heavy Duty PTFE Coated Aluminum Fittings
• Improved Support Clamp Auto-Centers Reactor and Lid Allowing Quick Installation/Removal Of Reactor
• Perfluoro O-Rings On 60mm and 200mm Flanges
• S.S. Inlet/Outlet Adapters Available In M16 x 1 and M30 x 1.5 Allow Connection To Cooling/Heating Circulator
• Lower Support Plate, and PTFE Ring, Have a "V" Shaped Opening Allowing An Unobstructed View Of Bottom Valve
• Zero Dead Space Detachable Drain Valve Has Knob with Laser Etched Directional Arrows For Open and Close
• Electric or Air Motor. Optional XP Motor Available
• 5-Neck Lid with Large Powder Addition Funnel
• Digital Temperature Monitor
• Electric Motor Has Separate Digital Controller
• Reactor Jacket Graduated On Both Sides
• Removable S.S. Pipe Used To Support Side Shelf and Manifold System
• Support Bushings For Optional Safety Shield
• Heavy Duty Lockable Casters

For Reactors Supplied with Mechanical Seal Stirrer Bearings: CLICK HERE

Email a Reactor Kit Specialist: [email protected]

Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1965-610
10L Process Reactor, Complete, Electric Motor, 70.1" OAH with Motor, 15.3" Clearance Below Valve
EACH
$19,756.00
Call for
Availability
CG-1964-610
10L Process Reactor, Complete, Air Motor, 67.0" OAH with Motor, 15.3" Clearance Below Valve
EACH
$18,391.50
Call for
Availability
CG-1965-610M
10L Process Reactor, Complete, Electric Motor, 70.1" OAH with Motor, 15.3" Clearance Below Valve, with CG-1969-M-01 Manifold System
EACH
$22,387.20
Call for
Availability
CG-1964-610M
10L Process Reactor, Complete, Air Motor, 67.0" OAH with Motor, 15.3" Clearance Below Valve, with CG-1969-M-01 Manifold System
EACH
$21,284.00
Call for
Availability
  ✱ Manufactured Glassware Product Line
Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-67Coupling, 2" Beaded Pipe, "A" 3-1/8" X "B" 1-5/16", 60 in-lbs MAX Torque, 7/16" Hex Nut SizeEACH
$177.75
Call for
Availability
Add to Favorites
CG-1968-66Coupling, 1" Beaded Pipe, "A" 1-7/8" X "B" 1-1/16", 35 in-lbs MAX Torque, 7/16" Hex Nut SizeEACH
$136.80
